    Fully Automatic Insulating Glass Vertical Production Line with CE ISO Certification

    Ask Lasest Price
    Supply Ability : 100sets/Month
    Certification : ISO 9001
    Delivery Time : Peak Season Lead Time: 1-3 months Off Season Lead Time: within 15 workdays
    Payment Terms : LC, T/T, D/P, PayPal, Western Union, Small-amount payment, Money Gram
    • Product Details
    • Company Profile

    Fully Automatic Insulating Glass Vertical Production Line with CE ISO Certification

    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    Structural features:
    1. This machine adopts the world's leading technology:
    2. The sheet metal of the parts in contact with water in the cleaning part are all made of stainless steel. The cleaning box is integrally welded by thick stainless steel, with high strength and no deformation.
    3. (Three pairs of brushes configuration) six 150mm diameter high temperature resistant silk brushes + four sprays, the glass is cleaned and the speed is fast (10-12m per minute). The first brush is equipped with two bristles with cylinder lifting, which can wash LOW-E glass.
    4. Each brush is driven by a motor to ensure more stable transmission of the brush.
    5. The stainless steel spring can automatically adjust the thickness of the cleaning glass from 3-20mm.
    6. The parts and screws in the cleaning box that are in contact with water are made of stainless steel, copper, waterproof aluminum, nylon and other materials, which will not rust after long-term use and are easy to maintain.
    7. Two pairs of aluminum profile air knives are equipped with high wind power and good air drying effect, with heating system. The unique circulating windshield drying system is energy-saving and low-noise (the wind temperature can reach 40 degrees without heating in winter).


    Technical parameter:
    Max Glass height1600mm
    Min Glass size400mm×400mm
    Glass thickness3mm-19mm
    Working speed1~10m/min
    Total power19KW
    Voltage380V/50Hz
    Machine size7200×2500×2300
    Weight2500KG
    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    CE ISO Insulating Glass Vertical Production Line Fully Automatic Insulating Double Layer Glass Washing and Drying Machine
    https://foshan-star.en.made-in-china.com/

    We make glass tempering furnace, glass edging machine, glass cutting machine, glass washing machine, glass drilling machine. Our company has more than 15 years.we have perfect after sales service and technology.contact with me if you have any request!
